ABB RET615 User Manual

0xA CS IEC 61850 name SA name Description Values
2133 6.05 .SPCS06.ctlVal Output 6 control 0/1=Off/On
2134 6.06 .SPCS07.ctlVal Output 7 control 0/1=Off/On
2135 6.07 .SPCS08.ctlVal Output 8 control 0/1=Off/On
2136 6.08 .SPCS09.ctlVal Output 9 control 0/1=Off/On
2137 6.09 .SPCS10.ctlVal Output 10 control 0/1=Off/On
2138 6.10 .SPCS11.ctlVal Output 11 control 0/1=Off/On
2139 6.11 .SPCS12.ctlVal Output 12 control 0/1=Off/On
2140 6.12 .SPCS13.ctlVal Output 13 control 0/1=Off/On
2141 6.13 .SPCS14.ctlVal Output 14 control 0/1=Off/On
2142 6.14 .SPCS15.ctlVal Output 15 control 0/1=Off/On
2143 6.15 .SPCS16.ctlVal Output 16 control 0/1=Off/On
2.5.9 LD0.SRGAPC1 Set-reset (8 pcs) (1)
Table 173: LD0.SRGAPC1 Set-reset (8 pcs) (1)
0xA CS IEC 61850 name SA name Description Values
LD0.SRGAPC1
2096 4.00 .Rs1.Oper.ctlVal Reset flip-flop 1 1=Reset
2097 4.01 .Rs2.Oper.ctlVal Reset flip-flop 2 1=Reset
2098 4.02 .Rs3.Oper.ctlVal Reset flip-flop 3 1=Reset
2099 4.03 .Rs4.Oper.ctlVal Reset flip-flop 4 1=Reset
2100 4.04 .Rs5.Oper.ctlVal Reset flip-flop 5 1=Reset
2101 4.05 .Rs6.Oper.ctlVal Reset flip-flop 6 1=Reset
2102 4.06 .Rs7.Oper.ctlVal Reset flip-flop 7 1=Reset
2103 4.07 .Rs8.Oper.ctlVal Reset flip-flop 8 1=Reset
2.5.10 LD0.SRGAPC2 Set-reset (8 pcs) (2)
Table 174: LD0.SRGAPC2 Set-reset (8 pcs) (2)
0xA
CS IEC 61850 name SA name Description Values
LD0.SRGAPC2
2104 4.08 .Rs1.Oper.ctlVal Reset flip-flop 1 1=Reset
2105 4.09 .Rs2.Oper.ctlVal Reset flip-flop 2 1=Reset
2106 4.10 .Rs3.Oper.ctlVal Reset flip-flop 3 1=Reset
2107 4.11 .Rs4.Oper.ctlVal Reset flip-flop 4 1=Reset
2108 4.12 .Rs5.Oper.ctlVal Reset flip-flop 5 1=Reset
2109 4.13 .Rs6.Oper.ctlVal Reset flip-flop 6 1=Reset
2110 4.14 .Rs7.Oper.ctlVal Reset flip-flop 7 1=Reset
2111 4.15 .Rs8.Oper.ctlVal Reset flip-flop 8 1=Reset
Section 2 1MRS756878 H
Modbus data mappings
88 RET615
Point List Manual
