2.4.1.34 LD0.PEMMTR1 Three-phase energy measurements
Table 137: LD0.PEMMTR1 Three-phase energy measurements
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.PEMMTR1
2100 u32 1 .SupWh.actVal Reverse active energy (high)
0..1E10
[kWh]
2101 .SupWh.actVal (low word)
2102 u32 1 .SupVArh.actVal Reverse reactive energy (high)
0..1E10
[kVArh]
2103 .SupVArh.actVal (low word)
2104 u32 1 .DemWh.actVal Forward active energy (high)
0..1E10
[kWh]
2105 .DemWh.actVal (low word)
2106 u32 1 .DemVArh.actVal Forward reactive energy (high)
0..1E10
[kVArh]
2107 .DemVArh.actVal (low word)
2.4.1.35 LD0.PEMMXU1 Power measurement demand values (1)
Table 138: LD0.PEMMXU1 Power measurement demand values (1)
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.PEAVMMXU1 Demand value
1939 i32 1 .TotW.mag Active power P (high) -/+ 999,999
1940 (Low word)
1941 i32 1 .TotVAr.mag Reactive power Q (high) -/+ 999,999
1942 (Low word)
1943 i32 1 .TotVA.mag Apparent power S (high) -/+ 999,999
1944 (Low word)
1945 i16 1000 .TotPF.mag Power factor -1…1
LD0.PEMAMMXU1 Max demand value
i32 1 .TotW.mag Active power P -/+ 999,999
i32 1 .TotVAr.mag Reactive power Q -/+ 999,999
i32 1 .TotVA.mag Apparent power S -/+ 999,999
LD0.PEMIMMXU1 Min demand value
i32 1 .TotW.mag Active power P -/+ 999,999
i32 1 .TotVAr.mag Reactive power Q -/+ 999,999
i32 1 .TotVA.mag Apparent power S -/+ 999,999
1MRS756878 H Section 2
Modbus data mappings
RET615 75
Point List Manual
