BitA RegA IEC 61850 name SA name Description Values
3265 204.01 .mcd
.mom-only Mom only alternative
3266 204.02 .SPCSO2.stVal X130-Output 2 State 0/1=Off/On
3267 204.03 .mcd
.mom-only Mom only alternative
3268 204.04 .SPCSO3.stVal X130-Output 3 State 0/1=Off/On
3269 204.05 .mcd
.mom-only Mom only alternative
2.3.1.73 LD0.XRGGIO130 Alarm/warning
Table 76: LD0.XRGGIO130 Alarm/warning
BitA RegA IEC 61850 name SA name Description Values
LD0.XRGGIO130
3032 189.08 .Alm.stVal - XRGGIO130 Alarm 1=Alarm
3033 189.09 .mcd
3034 189.10 .Wrn.stVal - XRGGIO130 Warning 1=Warning
3035 189.11 .mcd
2.3.2 Unmapped indications
Unmapped indications are indication data that have no initial Modbus mapping
locations, but can be added to the user-definable Modbus area using the
Communication Management tool in PCM600. If Modbus events are enabled for
these indication signals, the event identification is the user-definable area address.
2.3.2.1 All premapped three-phase protection function stages, operate/phase-
dependent objects added
Table 77: All premapped three-phase protection function stages, operate/phase-dependent objects added
BitA
RegA IEC 61850 name SA name Description Values
LD0.xxxxxxxx (various)
.Op.phsA Phs A operate 1 = Operate
.mcd
.Op.phsB Phs B operate 1 = Operate
.mcd
.Op.phsC Phs C operate 1 = Operate
.mcd
Section 2 1MRS756878 H
Modbus data mappings
46 RET615
Point List Manual
