Operation Manual / TPL73-B.. - 85-B11/ -B12
8 Disassembly and assembly / 8.8 Dismantling and installing the tur-
bine diffuser and nozzle ring
© Copyright 2018 . All rights reserved. HZTL2480_EN Revision D July 2018
8.8 Dismantling and installing the turbine diffuser
and nozzle ring
CAUTION
The nozzle ring (56001) must be secured to prevent it from falling be-
fore pulling out the turbine diffuser (63000). The nozzle ring just hangs
loosely on the positioning pins.
u Before disassembling the turbine diffuser (63000), the nozzle ring
(56001) must be secured to prevent it from falling down by using a
clamping set and a wooden block.
Page 110 / 151
