Operation Manual / TPL73-B.. - 85-B11/ -B12
7 Removal and installation / 7.3 Installing the turbocharger
© Copyright 2018 . All rights reserved. HZTL2480_EN Revision D July 2018
7.3 Installing the turbocharger
u Remove cover from oil connection.
u Fasten each of two sets of lifting gear to each of two bearing casing
ribs provided for this purpose. Ensure that ropes do not touch emer-
gency oil tank.
Under no circumstances loop a rope around the emergency oil tank and
suspend the turbocharger from it.
CAUTION
Oil orifice plates
An orifice plate for adjusting the oil pressure is fitted in each of the two
oil inlet channels in the bearing casing. When the cartridge group, the
bearing casing or the turbocharger is fitted to the engine, it must be
ensured that the orifice plates that are specified for the turbocharger
have been installed in the two oil inlet channels.
u Check correct installation of oil orifice plates.
u Adapt turbocharger to suit engine.
u Tighten fixing screws in foot in accordance with engine builder's in-
structions.
u Fasten gas, air and oil lines in accordance with engine builder’s in-
structions.
u Adapt insulating shell to suit bearing casing and fasten it.
u Plug in cable connector on speed sensor.
