ABB TRIO-WIRL ST4000 User Manual

Converter 4 - 4 PN25080
TRIO-WIRL INSTRUCTION MANUAL
4.3.2 Data Entry Overview
Action Use Keys= Display Information
Note:
The program protection
must be turned off before
data can be entered
(refer to Section 5.5.2)
Turn off Locked mode -
Qv % Standard-Display
10.5
↓↓↓
1) Advance to Progr. Level STEP or DATA
Progr.
Level
↓↓↓
2) Enter Menu ENTER
Locked
↓↓↓
ENTER Locked_ An "underscore"
indicates "selectable"
↓↓↓
3) Select desired Mode STEP or DATA
Standard_
↓
4) Enter Code (if not "0") ENTER
Program Protection Code
Direct Numeric Entry
Example: Set Qmax value
Entry from a Table
Example: Set meter size
Action Keys = Display Information Action Keys = Display Information
1) Find Parameter
“Qmax”
STEP or DATA
Qmax
1)Select parameter
"Meter size“
STEP or DATA
Meter
size
↓
2)Check “Qmax”
setting
ENTER
5.000
2) Check
"Meter Size“
ENTER
15 mm
l/s 1/2 in
↓
3) Change Parameter
“Qmax”
ENTER
0
3) Change parameter
"Meter Size“
ENTER
15 mm
l/s 1/2 in
↓
4) Enter the desired 4 . 5 2 5
4) Select "Meter
Size“ from table.
STEP or DATA
50 mm
number series l/s 2 in
4xDATA
5)Accept new
Meter Size
ENTER
Meter
STEP Size
10xDATA (decimal point)
STEP
5xDATA
STEP
2xDATA
STEP
5xDATA
4) *The C/CE key clears the entry
↓
5)Accept new Qmax
value
ENTER
4.525
l/s
Exit from Qmax or Meter Size
Find Program Level
STEP or DATA
*Prog. Level*
↓↓↓
Access parameter
setting
ENTER
Menu mode
↓↓↓
Turn program protection
on again (Step or Data)
ENTER
Menu mode
Locked_
↓↓↓
Select Program Level STEP or DATA Program level
↓↓↓
ENTER
↓↓↓
Return to Standard Display/
Process Information
C/CE
Qv %
Standard Display
10.5
!
