7.1.3 Flange Gaskets
* For higher process temperatures, refer to Figure 2-13 or 3-17 for Swirl and Vortex respectively.
Specifications for KLINGERsil C-4401 gasket material:
Liquids:
Operating Temperature Limit: 750
o
F
Gases & Steam:
Operating Temperature Limit: 450
o
F
Notes:
* Different O-Ring materials may be required for high
process temperature applications
* Temperature limits are valid at internal pressures of
<
400 psi
* The use of KLINGERexpert software system is
recommended for these extreme temperature
applications.
TABLE 7-5. FLANGE GASKETS
METER SIZE ANSI FLANGE
RATING
(POUNDS)
MAX. PRESSURE *
@ T
Proc
< 68
o
F (20
o
C)
( PSI )
QTY.
PART NUMBER.
INCHES MM VORTEX SWIRL
1/2 15
150
300
276
725
2
333J089U01
333J089U02
125
150
300
276
725
333J089U10
333J089U11
1-1/4 32
150
300
276
725
N/A
333J089U68
333J089U69
1-1/2 40
150
300
276
725
333J089U15
333J089U16
250
150
300/600
276
725/1436
333J089U19
333J089U25
380
150
300/600
276
725/1436
333J089U22
333J089U26
4100
150
300
276
725
333J089U29
333J089U30
600 1436
N/A 333J083U28
6150
150
300
600
276
725
1436
333J083U33
333J083U42
333J083U43
8200
150
300
600
276
725
1436
333J083U38
333J083U46
333J083U47
10 250
150
300
276
725
333J083U54
333J083U55
N/A
12 300
150
300
276
725
333J083U56
333J083U57
16 400
150
300
276
725
N/A
333J083U58
333J083U59
