PN25080 Converter 4 - 9
TRIO-WIRL INSTRUCTION MANUAL
FIGURE 4-8 OUTLINE DIMENSIONS, VR/SR IN WALL-MOUNT HOUSING
1.22
2.13 (1.46)*
4.92
2.24
3.94
2.76
( )* = w/o Display
All Dimensions Shown in Inches
