6 VIEW MENU
6.1 NAVIGATING THE MENU
1 2
VIEW
Status
Parameter
Error
Error log
Version
This menu is used possible to display a great deal of information related to machine
operation. Each label brings together a set of information so that the user can check
the status of the unit and any current errors or faults. The following keys are used
to navigate this menu:
1. Go back to the higher level menu;
2. Go back to the main page (Home).
To access a function, click on the text of that function.
6.2 VIEWING THE STATUS OF THE UNIT COMPONENTS (STATUS)
These pages display the status of the various components in the system. After ac-
cessing the "Status" function, you can browse the various pages using the buttons
on the left and right sides of the window. The following table shows the information
available, and the possible statuses.
NOTE: all information contained in this menu is "read only".
Label Meaning State
Compressor Indicates the current status of the compressor
On
O
Fan Indicates the current status of the fan
On
O
Unit status Indicates the status of the unit
Cooling
Heating
ACS
O
Circulator Indicates the current status of the fan
On
O
Water tank Status of the electric heater in the DHW storage tank
On
O
3-way valve 1 Not used --
3-way valve 2 Indicates the status of the 3-way valve on the system
On
O
Crankc. heater Indicates the status of the compressor casing heater
On
O
HP-heater 1
Indicates the status (for stage 1) of the optional electric heater, if installed (paragraph "7.9Setting an additional heater
(Optional E-heater)p.21")
On
O
HP-heater 2
Indicates the status (for stage 2) of the optional electric heater, if installed (paragraph "7.9Setting an additional heater
(Optional E-heater)p.21")
On
O
Chassis heater Indicates the status of the anti-freeze heater on the unit base
On
O
Plate heater Indicates the status of the anti-freeze heater on the plate heat exchanger of the unit
On
O
Defrost Indicates the current status of the defrosting cycle
On
O
Oil return Indicates the current status of the oil return cycle
On
O
Thermostat Indicates the current thermostat settings (paragraph "7.7Setting the use of an external thermostat (Thermostat)p.20")
O
Cooling
Heating
Other thermal Indicates the status of the additional heat source (paragraph "7.8Setting an additional heat source (Other thermal)p.20")
On
O
2 way valve Indicates the status of the 2-way valve on the system
On
O
HP-Antifree Indicates the status of the anti-freeze protection
On
O
External contact Indicates the status of the external contact (paragraph "7.15Activating auxiliary device management (Gate-Ctrl)p.23")
Card in
Card out
4-way valve Indicates the status of the 4-way valve on the unit
On
O
Anti-legionella
Indicates the current status of the anti-legionella cycle (paragraph "4.10Enabling/disabling the anti-legionella cycle
(Disinfection)p.12")
O
Progess
Done
Error
Flow switch Indicates the current status of the ow switch on the unit
On
O
