AG Duo Operation Manual
AR / 25.07.23 / Version 1 8
1.2.8 TRANSPORT AND LIFTING
• Always isolate the AG Duo before transporting or lifting.
• Ensure bystanders are at a safe distance when moving the AG Duo.
• Ensure all slings, chains or other lifting and moving devices are suitable and tested
for the weight of the AG Duo as defined in Section 3: Specifications
• Take care to avoid overhead power lines when lifting the AG Duo.
• DO NOT TOW THE AG DUO
• The Brush arm should be secured in its upright position before transport. Proceed as
follows:
o Note the position of the chassis lug.
o Ensure that the brush arm is fully upright.
o Release the lynchpin and pull the linkage pivot out, taking care that the brush
arm does not fall down.
o Rotate the linkage pivot and push back in so that it engages with the chassis
lug.
o Re-fit the lynchpin.
