AG Duo Operation Manual
AR / 25.07.23 / Version 1 14
2 ABOUT THE AG DUO
The AG Duo is a self-propelled bedding dispenser and cubicle brush. An optional scraper
blade can be fitted. It is designed to brush old bedding and manure off cubicles and to
dispense a variety of bedding products such as sawdust and EnviroBed.
The AG Duo is a fully electric machine. It consists of a driven axle, a hopper which holds the
bedding product, a rotary brush for sweeping cubicles, an auger and agitator combination
which moves the product within the hopper and a conveyor to dispense the product.
The AG Duo is intended for single person use. The operator has full control of the machine's
speed and rate of dispensing. The driven axle, the conveyor and the auger all have
independent speed controls and there is a metering shutter at the bottom of the hopper.
2.1 BRUSH
The Brush is mounted on an adjustable floating arm, allowing the brush to float over joins in
mats without lifting them. This also gives the operator the ability to add more pressure onto
the brush, useful for cleaning heavily soiled cubicles or cubicles that have not been
mechanically swept before. The brush linkage is driven by the actuator ram. +36 V from the
actuator circuit powers the ram.
2.2 AXLE
The AG Duo uses a +36 V Lithium battery to power a driven axle, reduce operator fatigue
and allow for a larger capacity bin.
