AG Duo Operation Manual
AR / 25.07.23 / Version 1 17
3.3 AIRBORNE NOISE EMISSIONS
Airborne noise emissions were measured at the operator’s position, at a height of 1.6m
from the floor within an open-ended shed. Background noise was measured at 36 dB.
With the AG Duo set to maximum conveyor speed and maximum auger speed and all other
functions activated, a maximum sound pressure level of 71 dB was measured.
As a general rule, the greater the discharge rate, the higher the noise level.
Operators should be aware of the local regulations concerning noise and take
the necessary steps to minimise the effects.
3.4 MACHINE IDENTIFICATION
The model and serial number of the dispenser are stamped on a plate located on the hopper
rim at the rear of the machine.
