AG Duo Operation Manual

AR / 25.07.23 / Version 1 44

6.2 CONVEYOR BELT REPLACEMENT

• Remove the conveyor from the AG Duo. Refer to Section 5.4.

• Slacken the conveyor belt. Refer to Section 5.3.

• Remove the conveyor side by removing the screws as indicated.

The conveyor can now be slid from the rollers for replacement. See Section 5.3 for belt

alignment and adjustment.

6.3 CONVEYOR ROLLER REPLACEMENT

Follow the procedure above.

NOTE: The end roller and the idler roller are NOT the same. The end roller is profiled and it

will not be possible to align the belt properly if the incorrect rollers are fitted.

Conveyor Belt

Idler Roller

End Roller

Conveyor Side
