Repairing the ALS Thermostat Module
Using the ESD Strap
Using the ESD Strap
Electronic boards are sensitive to electrostatic discharge (ESD). In order to
prevent damage, always use an ESD strap supplied in the autosampler
accessory kit, when handling electronic boards and components.
Using the ESD Strap
1 Unwrap the first two folds of the band and wrap the exposed adhesive side
firmly around your wrist.
2 Unroll the rest of the band and peel the liner from the copper foil at the
opposite end.
3 Attach the copper foil to a convenient and exposed electrical ground.
Figure 19 Using the ESD Strap
