204 Rockwell Automation Publication 1756-UM001M-EN-P - February 2012
Appendix A Status Indicators
• I/O Fault ModuleParent:X #XXXX message
The first part of the format is used to indicate the location of the faulted module.
How the location is indicated depends on your I/O configuration and the
module’s properties specified in RSLogix 5000 software.
The latter part of the format, #XXXX message, can be used to diagnose the type
of I/O fault and potential corrective actions. For details about each I/O fault
code, see the Logix5000 Major, Minor, and I/O Fault Codes Programming
Manual, publication 1756-PM014
.
Table 57 - I/O Fault Messages
Code Message
#0001 Connection Failure
#0002 Insufficient Resource
#0003 Invalid Value
#0004 IOI Syntax
#0005 Destination Unknown
#0006 Partial Data Transferred
#0007 Connection Lost
#0008 Service Unsupported
#0009 Invalid Attribute Value
#000A Attribute List Error
#000B State Already Exists
#000C Object Mode Conflict
#000D Object Already Exists
#000E Attribute Not Settable
#000F Permission Denied
#0010 Device State Conflict
#0011 Reply Too Large
#0012 Fragment Primitive
#0013 Insufficient Command Data
#0014 Attribute Not Supported
#0015 Data Too Large
#0100 Connection In Use
#0103 Transport Not Supported
#0106 Ownership Conflict
#0107 Connection Not Found
#0108 Invalid Connection Type
#0109 Invalid Connection Size
#0110 Module Not Configured
#0111 RPI Out of Range
