Watts Loss 2-213
Watts Loss The following table lists watts loss data for PowerFlex drives running at full
load, full speed and a factory default PWM Frequency of 4 kHz.
PowerFlex 70
For PowerFlex 70 drives, Internal Watts are those dissipated by the control
structure of the drive and will be dissipated into the cabinet regardless of
mounting style. External Watts are those dissipated directly through the
heatsink and will be outside the cabinet for flange mount and inside the
cabinet for panel mount.
Table 2.AC PowerFlex 70 Watts Loss at Full Load/Speed, 4kHz
(1)
(1)
Includes HIM.
PowerFlex 700
PowerFlex 700 drives are offered in panel mount versions only. At this time,
no method exists for venting outside of a secondary enclosure. This requires
enclosure sizing for total watts. see Table 2.AD
.
Table 2.AD PowerFlex 700 Watts Loss (Rated Load, Speed & PWM)
(2)
Voltage ND HP External Watts Internal Watts Total Watts Loss
480 0.5 11.5 17.9 29.4
1 27.8 19.5 47.3
2 43.6 21.6 65.2
3 64.6 24.0 88.6
5 99.5 28.2 127.7
7.5 140.0 27.8 167.8
10 193.3 32.0 225.3
15 305.4 34.2 339.6
20 432.9 42.9 475.8
240V 0.5 12.2 19.2 31.4
1 30.7 20.5 51.2
2 44.6 22.6 67.2
3 67.3 25.4 92.7
5 141.3 33.2 174.5
7.5 205.7 34.2 239.9
10 270.4 48.1 318.5
Voltage ND HP External Watts Internal Watts Total Watts Loss
240V 0.5 9 37 46
122 39 61
238 39 77
357 41 98
597 82 179
7.5 134 74 208
10 192 77 269
15 276 92 368
20 354 82 436
25 602 96 698
30 780 96 876
40 860 107 967
50 1132 138 1270
60 1296 200 1496
75 1716 277 1993
100 1837 418 2255
