Allen-Bradley Stratix 6000 User Manual

Rockwell Automation Publication 1783-UM001B-EN-P - May 2010 55
Appendix D
Data Layout
What This Appendix
Contains
This appendix provides information about the data layout for DINT input and
output bits.
DINT Input
These tables show the data layout.
Bit Bit
0
1
2
3
4
5
6
7
8
9
10
Unauthorized MAC ID on Network
Unauthorized MAC ID on Port 1
Unauthorized MAC ID on Port 2
Unauthorized MAC ID on Port 3
Unauthorized MAC ID on Port 4
Unauthorized MAC ID on Port 5
Unauthorized MAC ID on Port 6
Unauthorized MAC ID on Port 7
Unauthorized MAC ID on Port 8
Device Connected to Port 1(Link Active)
Device Connected to Port 2
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27…31
Device Connected to Port 3
Device Connected to Port 4
Device Connected to Port 5
Device Connected to Port 6
device Connected to Port 7
Device Connected to Port 8
Bandwidth Alarm on Port 1
Bandwidth Alarm on Port 2
Bandwidth Alarm on Port 3
Bandwidth Alarm on Port 4
Bandwidth Alarm on Port 5
Bandwidth Alarm on Port 6
Bandwidth Alarm on Port 7
Bandwidth Alarm on Port 8
Port Shut Off by PLC
IGMP Status
Reserved
Word Description
Word 1
Word 2
Word 3
Word 4
Word 5
Word 6
Word 7
Word 8
Word 9
Word 10
Word 11
Multicast Connections Active
TCP Connections Active
Bandwidth Used Port 1 (%)
Bandwidth Used Port 2 (%)
Bandwidth Used Port 3 (%)
Bandwidth Used Port 4 (%)
Bandwidth Used Port 5 (%)
Bandwidth Used Port 6 (%)
Bandwidth Used Port 7 (%)
Bandwidth Used Port 8 (%)
Bandwidth Scaling Factor
