3.7 Operation
–
Allow engine to warm up for 1 ... 2 min. when idling.
–
Adjust the engine speed control lever to full load position.
–
Adjust the direction of travel and speed at the control lever.
(See P. 3.2)
–
Guide and steer the machine at the tow bar, the operator
should go alongside the tow bar.
3.8 Water spray* (AVP 2620)
The water spray is switched on and off by the lever (1).
0 OFF
I Water spray front
II Water spray back
*Special eqiupment
3. Operation
0
III
1
Attention
Operate the machine only at full throttle and turn
the machine always in idle position during short
rest periods. Otherwise Danger of clutch damages
or slipping of centrifugal clutch.
Important
If there is a risk of frost, the spraying system should be
completeley emptied respt. filled with antifreeze.
33
b
a
0
1
2
min
max
B3299050.cdr
