10
use and maintenance RS 125
ARRANGEMENT OF THE MAIN ELEMENTS
KEY
1) Dashboard
2) Left rear-view mirror
3) Ignition switch/steering lock
4) Battery
5) Fuse carrier
6) Saddle lock
7) 2 stroke oil tank
8) 2 stroke oil tank plug
9) Glove/tool kit compartment
10) Passenger left footrest
(snapping, closed/open)
11) Rider left footrest
(with spring, always open)
12) Shifting lever
13) Side stand
14) Lower fairing
15) Horn
16) Left side fairing
1
1416
2
94
15
75
83 6
10
111213
RS_125_UK.book Page 10 Tuesday, June 13, 2006 1:34 PM
