57
use and maintenance RS 125
REMOVING THE LOWER FAIRING
u
Carefully read page 43
(MAINTENANCE)
Wait until the engine and the
exhaust silencer have
completely cooled down.
u
Loosen and remove the four screws (13),
on the right side and the other four on the
left side.
Handle the plastic and painted
components with care to avoid
scraping or damaging them.
Remove the lower fairing (14).
LIFTING THE FUEL TANK
Carefully read page 25 (FUEL) and
page 43 (MAINTENANCE).
Risk of fire.
Wait until the engine and the
exhaust silencer have
completely cooled down.
Fuel vapours are noxious for your
health.
Before proceeding, make sure that the
room in which you are working is
properly ventilated.
Do not inhale fuel vapours.
Do not smoke and do not use naked
flames.
DO NOT DISPOSE OF FUEL IN THE
ENVIRONMENT.
u
Remove the rider saddle, see page 56
(REMOVING THE RIDER SADDLE).
u
Unscrew and remove the screw (2) and
take the bushing.
u
Remove the fuel tank support rod (3)
from the relevant anchorage seats.
14
13
2
3
RS_125_UK.book Page 57 Tuesday, June 13, 2006 1:34 PM
