58
use and maintenance RS 125
u
Slightly raise the fuel tank (4) at the front
disconnect connector (5) and fuel line
(6).
u
Completely raise the fuel tank (4) and
slide in the rod (3) as shown:
AIR CLEANER
Clean the air cleaner every 4000 km
(2500 mi) or 12 months, change it every
8000 km (5000 mi) or more frequently if
the vehicle is used on dusty or wet roads.
It is possible to clean the air cleaner
partially after using the vehicle on this kind
of roads.
The partial cleaning of the filter
does not exclude or postpone
the replacement of the filter
itself.
REMOVAL
u
Lift the fuel tank, see page 57
(REMOVING THE LOWER FAIRING).
u
Unscrew and remove the two screws
(1).
u
Unscrew and remove the two screws (2)
and take the nuts positioned under them.
u
Remove the filter case cover (3).
u
Remove the filtering element (4) together
with the grids (5).
Plug the opening with a clean
cloth, to prevent any foreign
matters from entering the
suction pipes.
3
4
5
6
RS_125_UK.book Page 58 Tuesday, June 13, 2006 1:34 PM
