14
use and maintenance RS 125
INSTRUMENTS AND INDICATORS TABLE
When the ignition key is turned to " " with the engine stopped, all warning lights come on for a LED check-up and go out after two
seconds. If one or more warning lights do not come on at this stage, contact an aprilia Official Dealer
Description Function
Revolution counter rpm
Indicates the number of revolutions of the engine per minute.
Never exceed the engine max. speed rate, see page 41 (RUNNING-IN).
Direction indicator warning light Blinks when the direction indicators are on.
High beam warning light Comes on when the high beam bulbs are on or when the headlight signaller is operated.
Low fuel warning light
It comes on when the quantity of fuel left in the tank is approx. 3.5
b.
In this case, top up as soon as possible, see page 25 (FUEL).
Neutral indicator warning light Comes on when the gear is in neutral.
Error warning light
Comes on when the ignition switch is set to " " with the engine stopped as a lamp test.
If the light does not come on in this phase, contact an
aprilia Official Dealer.
If the light
remains on after the engine starts or comes on during
the normal operation of the engine, this means that low fluid level in
tank and mixer or high coolant temperature was detected.
In this case, check and/or top up to recommended fluid level and contact an aprilia Authorised
dealer, if necessary.
CAUTION
CAUTION
RS_125_UK.book Page 14 Tuesday, June 13, 2006 1:34 PM
