14
use and maintenance SR 50
ARRANGEMENT OF THE INSTRUMENTS / CONTROLS INSTRUMENTS AND INDICATORS
6
5
74
3
2
1 9 8
7a
9
1
2 3
4
568 7
KEY
1) Electrical controls on the left side of the handlebar
2) Rear brake lever
3) Left rear-view mirror
4) Instruments and indicators
5) Right rear-view mirror
6) Throttle grip
7) Front brake lever
8) Electrical controls on the right side of the handlebar
9) Ignition switch/steering lock (
- - )
KEY
1) Fuel level indicator ( )
2) Speedometer
3) Total kilometres odometer
4) Coolant temperature indicator (
)
5) Green direction indicator warning light (
)
6) Red 2 stroke oil reserve warning light (
)
7) Green low beam warning light (
)
7a) Blue high beam warning light (
)
8) Amber low fuel warning light ( )
9) Diagnostic system warning light (INJECTION CHECK)
