15
use and maintenance
SR 50
INSTRUMENT AND INDICATOR TABLE
It blinks when the direction indicators are on.
It comes on with the ignition switch in position ” ”, one brake lever pulled and the start push
button “ “ pressed, thus checking the correct operation of the bulb. If the light does not come
on during the starting, provide for replacing the bulb.
If the warning light comes on and does not go out after the start push
button “
” has been released, or if it comes on during normal func-
tioning, this means that the 2 stroke oil reserve is being used; in this case, top up the 2
stroke oil tank, see p. 23 (2 STROKE OIL).
It indicates the total number of kilometres covered.
It indicates the driving speed.
It comes on when the headlight is in low beam position.
It comes on when the headlight in high beam position.
It comes on when the quantity of fuel left in the tank is about 2
l.
It indicates the approximate fuel level in the tank.
It indicates the approximate temperature of the coolant in the engine.
When the pointer starts moving beyond the “min” level, the temperature is sufficient for driving
the vehicle. The normal running temperature range is indicated by the central area of the
scale.
If the pointer reaches the red area, stop the engine and check the coolant level, see p. 26
(COOLANT).
If the maximum allowed temperature is exceeded (red area “max” of
the scale), the engine may be seriously damaged.
Direction indicator warning light (
)
2 stroke oil reserve warning light ( )
Total kilometres odometer
Speedometer
Low beam warning light (
)
High beam warning light
( )
Low fuel warning light (
)
Fuel level indicator (
)
Coolant
temperature indicator (
)
Description
Function
Diagnostic system warning light
(injection check)
It lights up for a few seconds when the ignition switch is turned to the “ ” position. If the warning
light comes on, follow the instructions given on page 16 (INJECTION CHECK WARNING LIGHT).
If the light does not go out, the vehicle is malfunctioning. Do not at-
tempt to start it but contact an aprilia dealer.
CAUTION
CAUTION
CAUTION
