Asus ASMB7-iKVM User Manual

2-4 Chapter 2: Installation
2.3 Firmware update and IP conguration
You need to update the ASMB7-iKVM firmware and configure IP source before
you start using the ASMB7-iKVM board.
2.3.1 Firmware update
To update the firmware:
1. Insert the support CD into the optical drive.
2. Restart the remote server, then press <Del> during POST to enter the BIOS
setup.
3. Go to Boot menu and set the Boot Device Priority item to [CD-ROM].
4. When finished, press <F10> to save your changes and exit the BIOS setup.
5. On reboot, the main menu appears. Select
ASMB7-iKVM Firmware Update
for Clear Conguration, and press <Enter> to enter the sub-menu.
6. A confirmation message appears, asking whether you want to update the
firmware or not. Select <Yes> to update.
The firmware updating process starts.
WARNING !!!
UPDATE ASMB7 FIRMWARE NOW !
DO YOU WANT TO CONTINUE ?
No Yes

Asus ASMB7-iKVM Specifications

General

Brand	Asus
Model	ASMB7-iKVM
Category	Server Board
Language	English
