A-8 Appendix: Reference information
Hardware Monitor
Sensor No. Sensor Name Sensor Type Sensor Type Code Sensor Value or Event Type
0x31 CPU1 Temperature Temperature 0x01 Threshold(0x01)
Upper Non-critical - going high
Upper Critical - going high
0x32 CPU2 Temperature Temperature 0x01 Threshold(0x01)
Upper Non-critical - going high
Upper Critical - going high
0xCC TR1 Temperature Temperature 0x01 Threshold(0x01)
Upper Non-critical - going high
Upper Critical - going high
0xCD TR2 Temperature Temperature 0x01 Threshold(0x01)
Upper Non-critical - going high
Upper Critical - going high
0x34 VCORE1 Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x35 VCORE2 Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x36 +3.3V Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x37 +5V Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x38 +12V Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x39 +1.5V_ICH
(For Intel DP platform only -- ASUS Z8
series server MB; -E6 server system)
Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x3A +1.1V_IOH
(For Intel DP platform only -- ASUS Z8
series server MB; -E6 server system)
Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x3B +5VSB Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x3C VBAT Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x3D P1VTT
(For Intel DP platform only -- ASUS Z8
series server MB; -E6 server system)
Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
0x3E +1.5V_P1DDR3
(For Intel platform only -- ASUS Z8 series
server MB; -E6 server system)
Voltage 0x02 Threshold(0x01)
Lower Non-critical - going low
Lower Critical - going low
Upper Non-critical - going high
Upper Critical - going high
