Asus ASMB7-iKVM User Manual

2-6 Chapter 2: Installation
2.3.2 Congure BMC IP source static IP
1. Repeat the step 1-4 in the previous sub-section.
2. On reboot, the main menu appears. Select
Congure BMC IP Source Static IP
for LAN1 (or DM_LAN1), and press <Enter> to enter the sub-menu.
4. When the configuration is completed, the below screen appears.
3. A confirmation message appears, asking if you want to configure the BMC IP
source static IP now. Select <Yes> to continue.
5. Go to BIOS menu to set the IP. Refer to section 2.4 for IP settings in BIOS
menu.
WARNING !!!
CONFIGURE BMC IP Source STATIC IP NOW !
DO YOU WANT TO CONTINUE ?
No Yes
