Asus M2N-VM DH User Manual

ASUS M2N - V M D H 1-9
1.5.1 Motherboard layout
1.5 Motherboard overview
24.5cm (9.6in)
EATXPWR
KBPWR
Super I/O
DDR2 DIMM_B1 (64 bit,240-pin module) DDR2 DIMM_B2 (64 bit,240-pin module) DDR2 DIMM_A1 (64 bit,240-pin module) DDR2 DIMM_A2 (64 bit,240-pin module)
FLOPP
PRI_IDE
Y
SATA1 SATA2 SATA3 SATA4
Socket AM2
PWR_FAN
CHA_ FAN
SATA_RAID1
4Mb BIOS
CLRTC
CHASSIS
COM1
PANEL
USB910USB78IE1394_2AAFP
USBPW78
USBPW910
USBPW34
PCIE_SW
USBPW56
CDMP3IN
PCI1
PCI2
PCIEX16
PCIEX1_1
SB_PWR
ADI1988B
JMicron
JMB363
B5071A2KFBG
TSB43AB22A
CR2032 3V
Lithium Cell
CMOS Power
NVIDIA MCP61P
PS/2KBMS
T: Mouse
B: Keyboard
SPDIF_01
IE1394_1
SATA_USB12
LAN_USB34
AUDIO
DVI
USB56_WFGBT
CPU_FAN
ATX12V
LPT
VGA
R
M2N-VM DH
USBPW12
ADP3186
SPDIF_OUT
CHIP_FAN
24.5cm (9.6in
)

Asus M2N-VM DH Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of SATA connectors	5
I/O ports	1x WiFi-AP Solo antenna
Special features	ASUS WiFi-AP Solo Asus DH Remote ASUS MP3-In ASUS C.P.R. Q-Fan2 MyLogo2 EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrusion
Controller interface type	JMicron JMB363
Controller 2nd interface type	NVIDIA nForce 430
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS DH Remote Application ASUS WiFi-AP Solo Wizard Nvidia MediaShield RAID ASUS PC Probe 2 AMD Cool ' n' Quiet Utility ASUS LiveUpdate Utility Anti-Virus software (OEM)
Graphics card	GeForce 6100
Networking features	Gigabit Ethernet, Wireless LAN
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Width	245 mm
