M2N-VM DH specications summary
(continued on the next page)
CPU
Chipset
Front Side Bus
Memory
Expansion slots
Graphics
Storage
High Definition
Audio
Support AMD socket AM2 for AMD Athlon™ 64FX/
Athlon™ 64 X2/Athlon™ 64/Sempron processors
AMD64 architecture enables simultaneous 32-bit and
64-bit computing
Supports AMD Cool ‘n’ Quiet™ Technology
AMD Live!™ Ready
NVIDIA
®
GeForce™ 6100/nForce™ 430 MCP
2000/1600 MT/s
Dual-channel memory architecture
4 x 240-pin DIMM sockets support up to 8 GB of
unbufferred non-ECC 800/667/533 MHz
DDR2 memory modules
1 x PCI Express™ x16 slot
1 x PCI Express™ x1 slot
2 x PCI slots
Integrated in the NVIDIA
®
GeForce™ 6100 Graphics
Processing Unit (GPU)
Dual VGA output: DVI-D and RGB
High denition video processing with maximum
resolution of 1920 x 1440 pixels (@75Hz) for RGB
display, and 1600 x 1200 pixels (@65Hz) for DVI-D
display
Note: DVI-D only supports digital display. You
cannot convert DVI-D to output RGB signal to
CRT display.
NVIDIA
®
nForce™ 430 MCP media and communications
processor (MCP) supports:
- 1 x Ultra DMA 133/100/66/33 interfaces for two
hard disk drives
- 4 x Serial ATA 3 Gb/s hard disk drives supporting
RAID 0, RAID 1, RAID 0+1, RAID 5, and JBOD
conguration
JMicron
®
JMB363 SATA controller supports:
- 1 x Internal Serial ATA 3.0 Gb/s
- 1 x External Serial ATA 3.0 Gb/s on the rear panel
- RAID 0, RAID 1, and JBOD conguration
ADI AD1988 8-channel CODEC
Support Jack-Sensing, Enumeration, Multi-streaming
Technology
S/PDIF out interface

Asus M2N-VM DH Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of SATA connectors	5
I/O ports	1x WiFi-AP Solo antenna
Special features	ASUS WiFi-AP Solo Asus DH Remote ASUS MP3-In ASUS C.P.R. Q-Fan2 MyLogo2 EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrusion
Controller interface type	JMicron JMB363
Controller 2nd interface type	NVIDIA nForce 430
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS DH Remote Application ASUS WiFi-AP Solo Wizard Nvidia MediaShield RAID ASUS PC Probe 2 AMD Cool ' n' Quiet Utility ASUS LiveUpdate Utility Anti-Virus software (OEM)
Graphics card	GeForce 6100
Networking features	Gigabit Ethernet, Wireless LAN
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Width	245 mm
