ASUS M2N - V M D H 2-7
2.1.4 Updating the BIOS
The Basic Input/Output System (BIOS) can be updated using the
AwardBIOS Flash Utility. Follow these instructions to update the BIOS using
this utility.
1. Download the latest BIOS le from the ASUS web site. Rename the le
to M2N-VMDH.BIN and save it to a oppy disk, CD ROM or a USB ash
disk in FAT 16/12 format.
Save only the updated BIOS le in the oppy disk to avoid loading the
wrong BIOS le.
2. Copy the AwardBIOS Flash Utility (awdash.exe) from the Software
folder of the support CD to the oppy disk, CD ROM or a USB ash
disk with the latest BIOS le.
3. Boot the system in DOS mode using the bootable oppy disk, CD ROM
or a USB ash disk you created earlier.
AwardBIOS Flash Utility for ASUS V1.17
(C) Phoenix Technologies Ltd. All Rights Reserved
For MCP61-M2N-VM-DH-00 DATE: 04/13/2006
Flash Type - Winbond W39V080A 4Mb LPC
File Name to Program: M2N-VMDH.bin
Message: Do You Want To Save Bios (Y/N)
6. Type the BIOS le
name in the File Name
to Program eld, then
press <Enter>.
AwardBIOS Flash Utility for ASUS V1.17
(C) Phoenix Technologies Ltd. All Rights Reserved
Message: Please input File Name!
For MCP61-M2N-VM-DH-00 DATE: 04/13/2006
Flash Type - Winbond W39V080A 4Mb LPC
File Name to Program:
4. Under the DOS mode,
use <X:> (X stands for
the name of the disk
assignment) to switch
to the folder of the
oppy disk, CD ROM
or USB ash disk you
saved the BIOS le and
the Award BIOS Flash
Utility.
5. At the prompt, type awdash then press <Enter>. The Award BIOS
Flash Utility screen appears.

Asus M2N-VM DH Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of SATA connectors	5
I/O ports	1x WiFi-AP Solo antenna
Special features	ASUS WiFi-AP Solo Asus DH Remote ASUS MP3-In ASUS C.P.R. Q-Fan2 MyLogo2 EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrusion
Controller interface type	JMicron JMB363
Controller 2nd interface type	NVIDIA nForce 430
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS DH Remote Application ASUS WiFi-AP Solo Wizard Nvidia MediaShield RAID ASUS PC Probe 2 AMD Cool ' n' Quiet Utility ASUS LiveUpdate Utility Anti-Virus software (OEM)
Graphics card	GeForce 6100
Networking features	Gigabit Ethernet, Wireless LAN
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Width	245 mm
