2-24 Chapter 2: BIOS setup
DRAM Configuration
The items in the sub-menu show the DRAM-related information auto-
detected by the BIOS.
Select Menu
Item Specic Help
Auto, no user limit
MaxMemclk, limit by Memory
Clock value Manual, use
Memory
Clock value
Phoenix-Award BIOS CMOS Setup Utility
Advanced
Timing Mode [Auto]
x Memory Clock Frequency [Auto]
Tcl [Auto]
Trcd [Auto]
Trp [Auto]
Tras [Auto]
1T/2T Memory Timing [Auto]
DRAM Conguration
Timing Mode [Auto]
Sets the Timing mode. Conguration options: [Auto] [MaxMenClk]
[Manual]
Memory Clock Frequency [Auto]
Sets the memory clock frequency. Conguration options: [Auto]
[DDR2 400] [DDR2 533] [DDR2 667] [DDR2 800]
The Memory Clock Frequency is user congurable only when the Timing
Mode is set to MaxmenClk or Manual.
Timing Mode [Auto]
Sets the Timing mode. Conguration options: [Auto] [MaxMenClk]
[Manual]
Memory Clock Frequency [Auto]
Sets the memory clock frequency. Conguration options: [Auto]
[DDR2 400] [DDR2 533] [DDR2 667] [DDR2 800]
Tcl [Auto]
Conguration options: [Auto][3] [4] [5] [6]
Trcd [Auto]
Conguration options: [Auto] [3] [4] [5] [6]
Trp [Auto]
Conguration options: [Auto] [3] [4] [5] [6]
