Asus P11C-M/10G-2T User Manual

ASUS P11C-M/10G-2T
2-11
3. ConnecttheCPUfancabletotheconnectoronthemotherboardlabeledCPU_FAN1.
DONOTforgettoconnecttheCPUfanconnector!Hardwaremonitoringerrorscanoccurif
you fail to plug this connector.
2.3.3 Uninstalling the CPU heatsink and fan
4. Carefullyremovetheheatsinkandfanassemblyfromthemotherboard.
TouninstalltheCPUheatsinkandfan:
1. DisconnecttheCPUfancablefromthe
connector on the motherboard.
2. Rotate each fastener counterclockwise.
3. Pull up two fasteners at a time in a
diagonalsequencetodisengagethe
heatsink and fan assembly from the
motherboard.

Asus P11C-M/10G-2T Specifications

General

Brand	Asus
Model	P11C-M/10G-2T
Category	Motherboard
Language	English
