Asus P11C-M/10G-2T User Manual

2-14
Chapter 2: Hardware Information
2.4.3 Installing a DIMM on a single clip DIMM socket
3. HoldtheDIMMbybothofitsends
then insert the DIMM vertically into the
socket.Applyforcetobothendsofthe
DIMM simultaneously until the retaining
clip snaps back into place and the
DIMM cannot be pushed in any further
to ensure proper sitting of the DIMM.
Locked Retaining Clip
1. UnlockaDIMMsocketbypressingthe
retaining clip outward.
2. AlignaDIMMonthesocketsuchthat
the notch on the DIMM matches the
DIMM slot key on the socket.
Unlocked retaining clip
DIMM notch
DIMM slot key
1. Presstheretainingclipoutwardto
unlock the DIMM.
2. Remove the DIMM from the socket.
Removing a DIMM from a single clip DIMM socket
ToinstalltwoormoreDIMMs,refertotheuserguidebundledinthemotherboardpackage.
SupporttheDIMMlightlywithyourngerswhenpressingtheretainingclips.TheDIMM
mightgetdamagedwhenitipsoutwithextraforce.
AlwaysinserttheDIMMintothesocketverticallytopreventDIMMnotchdamage.
ADIMMiskeyedwithanotchsothatittsinonlyonedirection.DONOTforceaDIMM
into a socket in the wrong direction to avoid damaging the DIMM.
