5-28 Chapter 5: Software support
5.3.6 ASUS Fan Xpert
Asus Fan Xpert intelligently allows you to adjust both the CPU and chassis fan
speeds according to different ambient temperatures caused by different climate
conditions in different geographic regions and your PC’s system loading. The
built-in variety of useful proles offer exible controls of fan speed to achieve a
quiet and cool environment.
Install AI Suite from the bundled support DVD. To launch the ASUS Fan Xpert
utility, double-click the AI Suite icon on the Windows
®
notication bar and click
the Fan Xpert button on the AI Suite main window.
Click the dropdown list button and display the fan types. Select CPU Fan or
Chassis Fan.
Dropdown list button
Click to display
the dropdown list
and select a fan
prole mode
Click to display
the current CPU
temperature and the
fan speed ratio
Click to save the setup
Click to cancel the
Fan Xpert utility
Click to open the
Calibration wiondow

Asus P5QL-E - Motherboard - ATX Specifications

General

Form Factor	ATX
Chipset	Intel P43
CPU Socket	LGA 775
Maximum Memory	16 GB
Memory Type	DDR2
Memory Speed	1066/800/667 MHz
Memory Slots	4 x DIMM
Storage Interfaces	6 x SATA 3Gb/s, 1 x IDE
Compatible Processors	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	3 x PCI
USB Ports	12 x USB 2.0
LAN	Realtek RTL8111C Gigabit LAN
Audio	8-channel High Definition Audio
RAID Support	RAID 0, RAID 1, RAID 0+1, RAID 5
