ASUS P5QL-E 4-27
4.5.3 Onboard Devices Conguration
High Denition Audio [Enabled]
Allows you to enable or disable the High Denition Audio Controller. The following
item appears only when you enable this item.
Conguration options: [Enabled] [Disabled]
Front Panel Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to legacy
AC’97 or high-denition audio depending on the audio standard that the front
panel audio module supports. Conguration options: [AC97] [HD Audio]
SPDIF_OUT Mode Setting [SPDIF Output]
Conguration options: [HDMI Output] [SPDIF Output]
LSI Firewire1394 [Enabled]
Conguration options: [Enabled] [Disabled]
JMB IDE controller [Enabled]
Conguration options: [Enabled] [Disabled]
JMB MODE SELECT [IDE]
Conguration options: [RAID] [IDE] [AHCI]
Onboard PCIE GbE LAN [Enabled]
Onboard PCIEX GbE LAN. Conguration options: [Enabled] [Disabled]
LAN Option ROM [Disabled]
Onboard PCIEX GbE LAN Boot ROM conguration. Conguration options:
[Enabled] [Disabled
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
Onboard Devices Conguration
High Denition Audio [Enabled]
Front Panel Type [HD Audio]
SPDIF_OUT Mode Setting [SPDIF Output]
LSI Firewire 1394 [Enabled]
JMB IDE controller [Enabled]
JMB MODE SELECT [IDE]
Onboard PCIE GbE LAN [Enabled]
LAN Option ROM [Disabled]
Serial Port1 Address [3F8/IRQ4]
Enable or Disable
High Denition Audio
Controller
BIOS SETUP UTILITY
Advanced
