5-32 Chapter 5: Software support
6 Engine main menu
Auto Mode
Runs calibration
Turbo Mode
High Performance Mode
Medium Power Saving Mode
Max. Power Saving Mode
Advanced settings for each mode (refer to the next page for further information)
Displays CPU Power and
Total CPU Energy Saving
*Shifts between
the display of Total
and Current CO2
reduced
Displays the
amount of CO2
reduced
Displays the following
message if no VGA power
saving engine is detected.
Exits the utility
Displays the system
properties of each
mode
Displays
current
mode
Lights up when power
saving engine is activated
*• Click Current to show the CO2 that has been reduced since
you click the Renew button .
*• Click Total
to show the total CO2 that has been reduced
since you launched 6 Engine.

Asus P5QL-E - Motherboard - ATX Specifications

General

Form Factor	ATX
Chipset	Intel P43
CPU Socket	LGA 775
Maximum Memory	16 GB
Memory Type	DDR2
Memory Speed	1066/800/667 MHz
Memory Slots	4 x DIMM
Storage Interfaces	6 x SATA 3Gb/s, 1 x IDE
Compatible Processors	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	3 x PCI
USB Ports	12 x USB 2.0
LAN	Realtek RTL8111C Gigabit LAN
Audio	8-channel High Definition Audio
RAID Support	RAID 0, RAID 1, RAID 0+1, RAID 5
