Asus P5QL-E - Motherboard - ATX User Manual

ASUS P5QL-E 5-35
5.3.9 ASUS AI Direct Link
ASUS AI Direct Link allows you to form a computer-to-computer network via a
network cable to share les with high transfer rate. You must rst connect two
computers (at least one of them is ASUS product) using a network cable, and then
install the utility to both computers to avail the AI Direct Link feature.
• Turn off your rewall software other than Windows Firewall before
launching AI Direct Link.
• The transfer rate is limited if you use a 10/100 LAN card.
Using AI Direct Link
To enable the incoming folder:
1. From the Windows
®
taskbar, right click on the AI Direct Link icon and
select Incoming folder > Enable incoming folder.
2. If you want to to verify the incoming
user, select Use my account and
set your username and password.
Otherwise, select Use public
account.
For security’s sake, it is
recommended that you set a
username and password.
3. Click OK and the “Ready for incoming” message
appears.
To disable the incoming folder, select Incoming
folder > Disable incoming folder.
For Windows XP Home
edition users, click Steps of
enabling le sharing on this
pop-up message and follow
the instructions to enable the
incoming folder.

Asus P5QL-E - Motherboard - ATX Specifications

General

Form Factor	ATX
Chipset	Intel P43
CPU Socket	LGA 775
Maximum Memory	16 GB
Memory Type	DDR2
Memory Speed	1066/800/667 MHz
Memory Slots	4 x DIMM
Storage Interfaces	6 x SATA 3Gb/s, 1 x IDE
Compatible Processors	Intel Core 2 Quad, Core 2 Duo, Pentium, Celeron
Expansion Slots	3 x PCI
USB Ports	12 x USB 2.0
LAN	Realtek RTL8111C Gigabit LAN
Audio	8-channel High Definition Audio
RAID Support	RAID 0, RAID 1, RAID 0+1, RAID 5
