ATI Technologies Q46 Series User Manual

ATI Q46D Dissolved Oxygen System Part 10 - Troubleshooting
55
O&M Manual
Rev-N (4/21)
10.31 Display Messages
The Q46 Series instruments provide a number of diagnostic messages
which indicate problems during normal operation and calibration. These
messages appear as prompts on the secondary line of the display or as
items on the Fault List.
MESSAGE
DESCRIPTION
POSSIBLE CORRECTION
Max is 200
Entry failed, maximum user value allowed is 200.
Reduce value to ≤ 200
Min is 200
Entry failed, minimum value allowed is 200.
Increase value to ≥ 200
Cal Unstable
Calibration problem, data too unstable to
calibrate. Icons will not stop flashing if data is too
unstable. User can bypass by pressing ENTER.
Clean sensor, get fresh cal solutions, allow
temperature and conductivity readings to fully
stabilize, do not handle sensor or cable during
calibration.
Out of Range
Input value is outside selected range of the
specific list item being configured.
Check manual for limits of the function to be
configured.
Locked!
Transmitter security setting is locked.
Enter security code to allow modifications to
settings.
Unlocked!
Transmitter security has just been unlocked.
Displayed just after security code has been
entered.
Offset High
The sensor zero offset point is out of the
acceptable range of -40 to +40 mV.
Check wiring connections to sensor. Allow
sensor to operate powered a minimum of 12
hours prior to first zero cal.
Sensor High
The raw signal from the sensor is too high and
out of instrument range.
Check wiring connections to sensor.
Sensor Low
The raw signal from the sensor is too low.
Check wiring connections to sensor.
D.O. High
The oxygen reading is greater than the maximum
of the User-selected range.
The oxygen reading is over operating limits.
Set measuring range to the next highest level.
Temp High
The temperature reading is > 55ºC.
The temperature reading is over operating
limits. Check wiring and expected temp level.
Perform RTD test as described in sensor
manual. Recalibrate sensor temperature
element if necessary.
Temp Low
The temperature reading is < -10 ºC
Same as “Temp High” above.
TC Error
TC may be open or shorted.
Check sensor wiring and perform RTD test as
described in sensor manual. Check j-box
connections.
Figure 24 - Display Messages
