60
O&M Manual
Rev-N (4/21)
Spare Parts
Part No. Description
03-0393 Q46D Front Lid electronics assembly
07-0320 AC Powered monitor electronics assembly, 100-240 VAC
07-0321 DC Powered monitor electronics assembly 12-24 VDC
07-0322 AC Powered monitor electronics assembly w/Profibus, 100-240 VAC
07-0323 DC Powered monitor electronics assembly w/Profibus, 12-24 VDC
03-0407 P/S Assy, 100-240 VAC
03-0408 P/S Assy, 100-240 VAC with 3
rd
4-20mA output
03-0409 P/S Assy, 100-240 VAC with 3 relay exp. Board
03-0410 P/S Assy, 12-24 VDC
03-0411 P/S Assy, 12-24 VDC with 3
rd
4-20mA output
03-0412 P/S Assy, 12-24 VDC with 3 relay exp. Board
23-0029 Fuse, 630mA, 250V, TR-5 (for AC and DC Analyzers)
07-0078 Flow Type D.O. sensor
07-0095 Oxygen sensor, submersion type with 30’ cable
02-0007 Submersion sensing module, (for #07-0095)
02-0014 Submersion element body, (for #02-0007)
02-0113 Submersion holder, 30’ cable (for #07-0095)
02-0224 Flow Type Sensor Element (for 07-0078)
03-0358 Electrolyte Chamber with pressure gland
48-0001 Membrane holder, type 316 stainless steel
45-0010 Membrane holder, noryl
04-0003* Lead Electrode
05-0001* 5-mil Membranes, pkg. of 10
05-0011* 2-mil Membranes, pkg. of 10
05-0014 Spare Parts Kit, screw & o-ring (Submersible Sensor)
05-0015 Spare Parts Kit, screw & o-ring (Flow Sensor)
05-0088 Pressure gland rebuild kit
42-0014 Flowcell O-ring
09-0007* Dissolved oxygen electrolyte, 4 oz (120 cc)
07-0100 Junction box
31-0001 Interconnect cable for junction box to monitor wiring
38-0072 Terminal block plug, 3 position (Relays)
38-0073 Terminal block plug, 4 position (Outputs)
38-0074 Terminal block plug, 3 position (Cable Shields)
38-0081 Terminal block plug, 3 position (Power)
38-0084 Terminal block plug, 3 position (Power) – VDC version*
*NOTE: prior to Dec 2018, VDC (power) Terminal block used the (38-0081)
