Quick Setup Guide 3. Connecting to the Management Interface
BroadCloud SIP Trunk 17 AudioCodes Mediant BRI/PRI Gateway
3 Connecting to the Management Interface
This section shows how to connect to the device's management interface for the first time.
3.1 Default OAMP IP Address
The device is shipped with a factory default IP address for operations, administration,
maintenance, and provisioning (OAMP), through its VoIP LAN interface. Use this address
to initially access the device's embedded Web server. Default IP address is:
Table 3-1: Default VoIP LAN IP Address for OAMP
IP Address Value
IP Address 192.168.0.2
Prefix Length 255.255.255.0 (24)
Default Gateway 192.168.0.1
3.2 Connecting to the Embedded Web Server
To connect to the embedded Web server:
1. Connect Port 1 (leftmost LAN port) located on the front panel directly to the network
interface of your computer, using a straight-through Ethernet cable.
Figure 3-1: Connecting to the Embedded Web Server
