Quick Setup Guide C. AudioCodes ini File
BroadCloud SIP Trunk 41 AudioCodes Mediant BRI/PRI Gateway
C AudioCodes ini File
Shown below is the ini configuration file of the Mediant BRI Gateway, corresponding to the
Web-based configuration described in Section 2.
Note: To load and save an ini file, use the Configuration File page (Maintenance tab >
Software Update menu > Configuration File) in the Web interface.
;**************
;** Ini File **
;**************
;Board: Mediant 800
;HW Board Type: 69 FK Board Type: 72
;Serial Number: 3161551
;Slot Number: 1
;Software Version: 6.80A.263.005
;DSP Software Version: 5014AE3_R => 680.28
;Board IP Address: 195.189.192.139
;Board Subnet Mask: 255.255.255.0
;Board Default Gateway: 195.189.192.129
;Ram size: 369M Flash size: 64M Core speed: 300Mhz
;Num of DSP Cores: 1 Num DSP Channels: 30
;Num of physical LAN ports: 12
;Profile: NONE
;;Key features:;Board Type: 72 ;DATA features: ;IP Media: Conf VXML
VoicePromptAnnounc(H248.9) CALEA TrunkTesting POC ;Security: IPSEC
MediaEncryption StrongEncryption EncryptControlProtocol ;Coders: G723
G729 G728 NETCODER GSM-FR GSM-EFR AMR EVRC-QCELP G727 ILBC EVRC-B AMR-WB
G722 EG711 MS_RTA_NB MS_RTA_WB SILK_NB SILK_WB SPEEX_NB SPEEX_WB ;DSP
Voice features: IpmDetector RTCP-XR AMRPolicyManagement ;QOE features:
VoiceQualityMonitoring MediaEnhancement ;FXSPorts=4 ;FXOPorts=4 ;Channel
Type: DspCh=30 IPMediaDspCh=30 ;HA ;Control Protocols: MSFT CLI
TRANSCODING=60 FEU=100 TestCall=100 EMS MGCP SIP SASurvivability SBC=60
;Default features:;Coders: G711 G726;
;------ HW components------
;
; Slot # : Module type : # of ports
;----------------------------------------------
; 1 : BRI : 4
; 2 : Empty
; 3 : Empty
;----------------------------------------------
[SYSTEM Params]
EnableSyslog = 0
NTPServerUTCOffset = 7200
NTPServerIP = '0.0.0.0'
LDAPSEARCHDNSINPARALLEL = 0
[BSP Params]
PCMLawSelect = 0
[Analog Params]
[ControlProtocols Params]
AdminStateLockControl = 0
