Appendix A. Standard Specifications
Valve body
Basic model
No.
: AGVB_ _ _ (for JIS10K, ANSI150, JPI150)
AGVM_ _ _ (for JIS16K, 20K, 30K, ANSI300,
JPI300)
Type : Straight-through, cast globe valve
Connection
diameter
(inches)
: 1/2, 3/4, 1, 1-1/2, 2, 2-1/2, 3, 4
Pressure rating: JIS10K, 16K, 20K, 30K,
ANSI150, 300, JPI150, 300
Flange type: RF
Welding type (optional): socket welded,
butt welded
Material : For body and trim material combina-
tions and operating temperature ranges,
Table A-1.
Bonnet : General (-17 to +230°C)
Extension, type 1 (230 to 400°C and -45to
-17°C)
Extension, type 2 (-196 to -45 °C)
Gland type : Bolted gland
Packing,
grease
: PTFE yarn packing (for general use): grease
not included
V-shaped PTFE packing (for degreased
models, for low temperature): grease not
included
V-shaped PTFE packing (direct + reverse)(for
vacuum service): grease not included
Graphite yarn (for high temperature): grease
included
Gasket : For combination of the bonnet-body
gasket and the seat ring-body gasket,
see table 5, “Selection of Gasket” in the
specifications sheet for this product (No.
SS2-AGV200-0001).
Trim
Valve plug : Contoured plug
Seat type : Metal seat, soft seat
Flow
characteristics
: Equal percentage
But linear characteristics if the rated Cv is
0.1, 0.16, or 0.25
Material : For body and trim material combina-
tions and operating temperature ranges,
Table A-1.
Actuator
Type : Multi-spring diaphragm actuator (PSA)
Action : Direct action, reverse action
Diaphragm
material
: Cloth-embedded ethylene-propylene
Yoke material : SCPH2 (A216WCB)
Spring range: 20–98 kPa, 80–240 kPa,
100–180 kPa, 200–340 kPa
Supply air
pressure:
140–400 kPa
Air supply
connection:
Rc 1/4 or NPT 1/4 female thread
Ambient
temperature:
-30 to +70 °C
Valve action
Direct action (use in combination with a direct-action
actuator)
Reverse action (use in combination with a reverse-action
actuator)
Optional accessories
Positioner, pressure regulator with air filter, handwheel,
limit switch, solenoid valve, travel transmitter, booster
relay, lock-up valve, etc.
Note: The VPE positioner can be installed only on the
PSA1 actuator.
A-1
