HOW TO ADJUST MARQUEE HEIGHT
Each side of the marquee support is equipped with a height
adjustment system, allowing flexibility in height from 109” to
123”
Remove casters before installing marquee for 9 foot ceiling
height. (107”)
Loosen the upper bolts on the both sides and remove the
lower bolts using a 9/16” wrench.
Lift the marquee up, allowing bolts to ride in the grooves.
Select your desired height and allow the marquee to slide
back down and rest in the notches.
Re-install the lower bolts and re-tighten the upper bolts to
hold the marquee securely.
LOOSEN
REMOVE
HOW TO ACCESS BALL TUBE FILL SENSOR
Release the 2 latches on the right side of the
marquee and swing open the large round marquee
This provides access to the Ball Tube Fill Sensor.
