Setting up the machine8
To remove
· raise the needle
· turn power switch to 0
· open the accessory box
cover
· open the bobbin cover
· grasp the latch of the
bobbin case
·remove case
Bobbin case
Note:
For normal sewing, the
bobbin thread does not have
to be brought up as the loose
end is just the right length to
start sewing.
To insert
· hold the bobbin case
latch
· the opening on the case
should be at the top
· insert so that it engages
· close the bobbin cover
· close the accessory box
cover
Bobbin thread cutter
· insert the bobbin case
· take thread over cutter A
· cut thread
Inserting the bobbin
The bobbin must turn
clockwise when the thread
is pulled.
Insert the bobbin so that
the thread runs clockwise.
Pull the thread counter-
clockwise into the slot.
Pull the thread to the left
under the spring until it
lies in the T-shaped slit at
the end of the spring.
Winding the bobbin
Winding the bobbin
· turn power switch on
· place empty bobbin on
spindle
Refer to the safety
instructions!
Thread cutter
· cut the thread on the
thread cutter
Threading the bobbin
· following the direction of the arrow take thread through
the rear guide and round the pre-tension stud
· wrap the thread around the inner bobbin two or
three times and cut off any excess thread on the thread
cutter
·press the engaging lever against the bobbin
·press the foot control
the motor stops automatically when the bobbin is full
·remove the bobbin
A
BA_165_engl 16.4.2004 9:34 Uhr Seite 8
030787.52.04_0401_a165_EN
