1 689 988 238 2012-11-06| Robert Bosch GmbH
96 | ACS 651/751 | Troubleshootingen
Error code Messages Actions
D001 A/C PERFORMANCE TEST
Refrigerant cylinder full
R Weight limit reached. Reduce quantity of refrigerant in internal refrigerant cylin
-
der.
R Load cell is defective. Replace the load cell.
D002 A/C PERFORMANCE TEST
Service Timeout
R Check for leakage / blockage in the HP/ LP hoses of the ACS 651/751.
R Check if the quick couplers are connected properly to the service connections on
the vehicle A/C system.
R Contact customer service.
D003 A/C PERFORMANCE TEST
High pressure in the system, Per
-
form Hose drain
The pressure is greater than 1400 mbar. Perform hose drain (see chapter 6.11).
D004 A/C PERFORMANCE TEST
Insufficient R134a Quantity
Fill the internal refrigerant cylinder.
D005 A/C PERFORMANCE TEST
High pressure shutdown
R Check the connection to the high pressure switch
R Check if the hose connection to the blue valve on the cylinder is open.
R Check for blockage in the blue hose.
E005 OIL RECHARGE
High pressure in system
Perform vacuuming
*)
The message "Service Timeout" indicates the service timeout for any service phase which is in progress. The fol-
lowing table indicates the service timeout duration for different service phases.
Service phase Timeout duration (mins)
Recovery (refrigerant recovery) 90
Recharge oil 3
Recharge UV dye 3
Recharge refrigerant 15
Hose drain 5
