AutoDome Pipe Mount Cable and Wire Standards | en 35
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
3.3.5 Using a Fiber Optic Ethernet Media Converter to
Transmit Video and Control
The fiber optic media converter kit, available for AutoDome 700
Series cameras, is designed to transmit 10/100 Mbps Ethernet
signals over fiber optic cable using 10/100 Mbps Small Form-
factor Pluggable (SFP) modules. The SFP modules are available
as multi-mode fiber (MMF) or single-mode fiber (SMF) models
with a single SC connector or dual-fiber with an LC connector.
Refer to the VG4-SFPSCKT Fiber Optic Media Converter
Installation Guide.
3.4 Control-only Cables
3.4.1 Controlling the AutoDome via Biphase
(Shielded 2-wire, half-duplex, multi-drop, 5000 ft. cable limit)
Biphase is the standard Bosch protocol used to send Pan/Tilt/
Zoom control over 2-wire shielded twisted pair (STP)
terminated with a 100 Ω terminal resistor.
The AutoDome has a 100 Ω termination resistor between the
Biphase C+ and C- terminals.
Ethernet Media Converter
Data Interface Ethernet
Data Rate 10/100 Mbps
IEEE 802.3 Compliant
Full Duplex or Half Duplex Electrical Port
Full Duplex Optical Port
Fiber Type, MMF 50/125 µm MMF. For 50/125 µm fiber, subtract 4 dB
from the specified optical budget value. Must meet or
exceed fiber standard ITU-T G.651.
Fiber Type, SMF 8–10/125 µm SMF. Must meet or exceed fiber standard
ITU-T G.652.
Maximum Distance 60 km (37.3 miles)
Requirement Media converter receiver (CNFE2MC/IN) at controller
end of system
Terminal
Connection
Duplex LC or Single SC
