AutoDome Pipe Mount Cable and Wire Standards | en 43
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
3.6 Audio Cables
The VG5 700 Series AutoDome is capable of receiving line input
audio signals and transmitting it over a network. The audio
signal is transmitted one-way and in sync with the video signals.
Audio Line Input Specifications
Wire Specifications
Max. Input Voltage 5.5 Vpp
Impedance 9K Ω
Sample Rate 8 K Hz, 16 Bit, mono
Shield Bare copper braid: 95% coverage
Internal gain level adjustment is available
Wire Type
Coax
3
(recommended)
Distance 10 m (33 ft)
Gage 22 AWG to Biphase connector (P105/P106)
Shield Bare copper braid: 95% coverage
Center conductor Stranded bare copper
NOTICE!
Separate the audio cables from the AC power lines to avoid
noise.
