2. SPECIFICATIONS
BAS-326G PS
2
2. SPECIFICATIONS
Sewing machine Lock stitch pattern tacking sewing machine
Stitch formation Single needle lock stitch
Max. sewing speed 2,700 sti/min
Sewing area (XxY) Max. 220 x 100 mm
Feed mechanism Intermittent feed, pulse motor drive
Stitch length
0.05 − 12.7 mm
No. of stitches 500,000-stitch internal memory (*)
Maximum no. of stitches 20,000 stitches (per program)
No. of sewing data items
that can be stored
Internal memory: 512 (*), CF card: 900
Work clamp lift method Pneumatic method
Work clamp height Max. 30 mm
Intermittent presser foot lift
amount
19.5 mm
Intermittent stroke
2 − 4.5 mm, 4.5 − 10 mm or 0 (Default setting 3 mm)
Hook Double-capacity rotary hook
Wiper device Standard equipment
Thread trimmer Standard equipment
Data storage method
Internal memory (Flash memory), CF card (32 MB − 2 GB)
[Option] 3.5 floppy disk 2HD/1.44MB, 2DD
User programs 50
Cycle programs 9
Motor 550 W AC servo motor
Weights
Machine head approx. 90 kg, operation panel approx. 0.6 kg
Control box 14.2 − 16.2 kg (Differs depending on destination)
Power supply Single-phase 100 V/220 V, Three-phase 200 V/220 V/380 V/400 V 400 VA
Air pressure 0.5 MPa 1.8 l/min.
* The number of data items and stitches that can be stored will vary depending on the number of stitches in each program.
