Brother P-touch 9700PC User Manual

12
Connecting the printer
Connect the printer to the power source and a computer.
Connecting to the power source
1
Connect the included power supply
cord to the AC adapter.
2
Insert the AC adapter connector into
the AC adapter socket on the back of
the printer.
3
Plug the power supply cord into an
electrical outlet (AC 220 to 240 V).
4
Turning on the printer
Turn on the main power switch on the
back of the printer, and then press the
power button on the front of the printer.
Turning off the printer
Hold down the power button on the front
of the printer until the printer is turned off,
and then turn off the main power switch
on the back of the printer.
DC IN 24V
DC IN 24V
Note
● Always turn the power off first using the
power button on the front of the printer
before removing the AC adapter or
turning off the main power switch.
● After using the printer, disconnect the
power supply cord from the electrical
outlet and the AC adapter from the
printer and store them for future use.
● When removing the AC adapter always
pull the plug. Do not pull the AC adapter
or power supply cord. The wire in the
cords may break.
● Do not use any AC adapter other than
the one included with the printer. Failure
to observe this may result in an accident.
DC IN 24V
STATUS
STATUS
Power
button
Main power
switch

Brother P-touch 9700PC Specifications

General

Vertical printing	Yes
Maximum resolution	360 x 720 DPI
Standard interfaces	USB 2.0
Tape type	TZ
Tape cutting	Automatic
Internal memory	2 MB
Built-in barcodes	Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E
Dimensions (WxDxH)	116 x 192.7 x 140 mm
Minimum system requirements for Macintosh	- RAM 128 MB - HDD 50 MB - USB (1.1/2.0)
Minimum RAM	512 MB
Compatible operating systems	Windows 2000 Pro/XP/7/Vista, Mac OS 10.3.9 - 10.6
Maximum label width	27.1 mm
Maximum label length	8 m
Product color	Gray

Weight and Dimensions

Depth	192.7 mm
Width	116 mm
Height	140 mm
Weight	1570 g
