Brother P-touch 9700PC User Manual

26
Distributed printing
When printing a large number of labels, printing
can be distributed among multiple printers.
Since printing is performed at the same time,
the total printing time can be reduced.
1
From the “File” menu in
P-touch Editor 5.0, click “Print”.
2
Click [Properties...].
3
Select the “Advanced” tab, select the
“Distributed printing” check box, and
then click [Settings].
4
In the “Distributed Printing Settings”
dialog box, select the printers to be
used for distributed printing.
1. Click [Detect Current Paper
Information].
2. The current printer information that
was detected appears below “Current
Width” and “Paper Type”.
3. Select the check box beside the
“Printer Name” to be used for
distributed printing.
Note
● Printing can be distributed to printers
connected via a USB connection or
network connection (PT-9800PCN only).
● The number of pages to be printed is
automatically divided among the selected
printers. If the specified number of pages
cannot be evenly divided among the
printers, it will be divided in the order
of the printers listed in the “Distributed
Printing Settings” dialog box when the
print settings are specified in step
4.
67 67
66
200
3
1
2

Brother P-touch 9700PC Specifications

General

Vertical printing	Yes
Maximum resolution	360 x 720 DPI
Standard interfaces	USB 2.0
Tape type	TZ
Tape cutting	Automatic
Internal memory	2 MB
Built-in barcodes	Codabar (NW-7), EAN13, EAN8, Maxicode, Postnet, QR Code, UPC-A, UPC-E
Dimensions (WxDxH)	116 x 192.7 x 140 mm
Minimum system requirements for Macintosh	- RAM 128 MB - HDD 50 MB - USB (1.1/2.0)
Minimum RAM	512 MB
Compatible operating systems	Windows 2000 Pro/XP/7/Vista, Mac OS 10.3.9 - 10.6
Maximum label width	27.1 mm
Maximum label length	8 m
Product color	Gray

Weight and Dimensions

Depth	192.7 mm
Width	116 mm
Height	140 mm
Weight	1570 g
